This proposal details a comprehensive and scalable energy storage solution designed for modern homeowners. Our system empowers households to achieve greater energy independence, significantly reduce electricity costs, and build resilience against increasing power outages. By seamlessly integrating with new or existing solar panel installations, this solution unlocks the full potential of solar energy, transforming how families power their lives.Based on our calculations of factors like daily sunlight hours, we recommend a 5kWh solar power system configuration consisting of: one 5kWh battery, one 6.2kW inverter, and two 610W solar panels.

Item	5KWH	10KWH	15KWH
Product Model	TY-FL-5KWH	TY-FL-10KWH	TY-FL-15KWH
configuration	16S1P	16S1P	16S1P
Rated Energy	5.12KWH	10.24KWH	16.07KWH
Rated Voltage	51.2V	51.2V	51.2V
Battery Capacity	100Ah	200Ah	314Ah
Max. charging current	100A	200A	314A
Charge Cutoff Voltage	59.2V	59.2V	59.2V
Continuous Discharge Current	50A	100A	157A
Discharge cutoff voltage	44V	44V	44V
Cycle Life	6000 cycles	6000 cycles	6000 cycles
Charge efficiency	≥98%	≥98%	≥98%
Maximum Continuous Discharge Rate	≥96%	≥96%	≥96%

Item	6.2KW	11KW
AC Input	220V/110V	220V/110V
Input Voltage Range	90-280VAC±3V	90-280VAC±3V
Input Frequency	50/60Hz±5%	50/60Hz±5%
Rated Power	6200W	11000W
PV Inverter output Power	6500W	12000W
output voltage	220/230/240VAC±5%	220/230/240VAC±5%
○utput Frequency	50/60Hz±0.1%	50/60Hz±0.1%
Peak Power	12400VA	22000VA
Grid Voltage Range	170-265VAC	170-265VAC
BatteryRated Voltage	48Vdc	48Vdc
PV Charging Mode	MPPT	Dual MPPT
Max PV Input Power	8500w	2×7500w
MPPT Input Voltage Range	60-500vdc	90~500Vdc
Max PV Charging current	120A	150A

Rated Power (Pmpp)			610W
Rated Current (Impp)	14.84A
Rated Voltage (Vmpp)			41.11V
Short Circuit Current (Isc)			15.48A
Open Circuit Voltage (Voc)			48.95V
Module Efficiency (%)			22.58%
Maximum Power (Pmax)			672W
Optimum Operating Current (Impp)			16.35A
Optimum Operating Voltage (Vmpp)			41.11V
Weight			32.6Kg
Dimension			2382*1134*30mm
