Battery Module (1P52S Cell)
| Capacity | 52.25KWH |
| Configuration | 52S1P |
| Nominal Voltage | 83.2V |
| Cell Capacity | 314Ah |
| Dimension | 442*1050*235mm |
| Weight | 165KG |
Inverter Specifications
| AC Rated output power | 300KW |
| AC Maximum output power | 315KW |
| Rated voltage | 400.0V |
| Rated frequency | 50/60Hz |
| Maximum PV input voltage | 1000.0V |
| MPPT operating voltage range | 250V-850V |
| MPPT full load voltage range | 450V-850V |
Connection Method & System Introduction
Connection Point: 800kVA Transformer Distribution Room
The system is connected at a voltage level of 380V AC utilizing an AC (440Vac) coupled configuration.
Energy Storage Dashboard
Monitor and manage the entire factory's electricity consumption, revenue, and real-time data intuitively.
One-click report generation and remote real-time statistics.
Frequently Asked Questions
1. Is the 783kWh system suitable for medium-sized industrial facilities?
Yes, the 783kWh capacity paired with a 300kW inverter is an optimal balance for medium-sized factories looking to reduce peak demand charges and ensure power stability.
2. What are the benefits of the 314Ah LFP cells in this configuration?
Our 314Ah cells offer higher energy density and a longer cycle life compared to traditional cells, ensuring the 783kWh system remains compact while delivering high performance.
3. Can I expand the capacity if my energy needs grow?
Absolutely. The modular design of our ESS allows for parallel expansion, meaning you can add more units to increase both storage capacity and power output as your factory expands.
4. Does the system support remote monitoring and control?
Yes, our integrated Energy Management System (EMS) provides a cloud-based dashboard accessible via web or mobile for real-time monitoring of ROI and system health.
5. How does the fire protection system work?
The system includes a multi-level safety design with per-module temperature monitoring and an automated fire suppression system to ensure maximum safety for industrial environments.
6. What is the installation timeframe?
Since the system is pre-configured and tested in our factory, on-site installation is simplified to basic positioning and AC cabling, typically completed within a few days.
7. Is it compatible with existing Grid-Tied solar systems?
Yes, the AC-coupled design allows it to integrate seamlessly with your current solar setup, capturing excess solar energy for use during peak hours.
Fire Protection System for C&I Energy Storage
Wiring Methods for C&I Energy Storage
Product Care and After-sales Service
