| Capacity | 5.12KWH | 10.24KWH |
| Configuration | 16S1P | 16S1P | |
| Nominal Voltage | 51.2V | 51.2V | |
Cell capacity | 100Ah | 200Ah | |
Voltage rang | 40~58.4V | 40~58.4V | |
Maximum output power | 5500W | 5500W | |
MPPT voltage range | 120~500V | 120~500V | |
Rated output power | 5000W | 5000W | |
| Rated output voltage | 90-280Vac (Normal Mode) | 230Vac±5% | |
Output frequency rang | 50Hz ± 0.3Hz /60Hz ±0.3 Hz | 50Hz ± 0.3Hz /60Hz ±0.3 Hz | |
Communication methods | RS485、Dry Contact、CAN、WIFI/4G | CAN, RS485/wifi/GPRS | |
Installation mod | Wall-mounted | Wall-mounted | |
| Weight | 57k | 100kg | |
| Size (height * width * depth) | 850*480*160mm | 1100*540*160mm |
Connection Point: 800kVA Transformer Distribution Room
Energy Storage System Connection: Connected at a voltage level of 380V AC, as shown in the diagram below.
Connection Method: Utilizes an AC {440Vac) coupled grid-connected pipeline configuration.
{As illustrated in the diagram below.)
Energy Storage Dashboard: When powered on, users can log in to monitor and manage the entire factory's electricity consumption, revenue, etc.
The system's entire homepage retrieves real-time data, making it highly intuitive.
Earnings can be easily exported, with one—click report generation and real—time remote statistics.
