 | Capacity | 5KWH | 10KWH | 16KWH |
| Configuration | 16S1P | 16S1P | 16S1P | |
| Nominal Voltage | 51.2V | 51.2V | 51.2V | |
Cell capacity | 100Ah | 200Ah | 314Ah | |
| Cycle Life | 6000 cycles | 6000 cycles | 6000 cycles | |
| Charging Voltage | 54.5-58.4V | 54.5-58.4V | 54.5-58.4V | |
Charging Current | 20A | 20A | 50A | |
Max. charging current | 100A | 200A | 314A | |
Charge Cutoff Voltage | 59.2V | 59.2V | 59.2V | |
Discharge cutoff voltage | 44V | 44V | 44V | |
| Dimension | 700*500*620mm | 700*500*620mm | 700*500*620 | |
| Weight | 75Kg | 90Kg | 105Kg |
Connection Point: 800kVA Transformer Distribution Room
Energy Storage System Connection: Connected at a voltage level of 380V AC, as shown in the diagram below.
Connection Method: Utilizes an AC {440Vac) coupled grid-connected pipeline configuration.
{As illustrated in the diagram below.)
Energy Storage Dashboard: When powered on, users can log in to monitor and manage the entire factory's electricity consumption, revenue, etc.
The system's entire homepage retrieves real-time data, making it highly intuitive.
Earnings can be easily exported, with one—click report generation and real—time remote statistics.
Fire Protection System for Commercial & Industrial Energy Storage
Introduction to Wiring Methods for Commercial & Industrial Energy Storage Systems
Product Care and After-sales Service
